CS-HPE SERIES

Cooling capacity 220/1510 kW

Frame

Frame made of galvanized steel sheet for an effective resistance to corrosive agents.

Compressors are placed below the finned coils to reduce the overall sizes without impacting on performances.

Compressors

Hermetic Scroll compressors designed to operate with R454B refrigerant, driven by electric motors and connected in tandem or trio version to maximize efficiency at partial loads.

R454B is a next generation A2L refrigerant with a GWP of only 467, one of the lowest on the market. This GWP value ensures that the range complies with the gradual reduction of greenhouse refrigerant emissions required by the F-GAS regulation, down to the stricter limits foreseen for 2030.

Fans

High pressure variable speed EC fans controlled by Inverter allowing a raised energy savings.

Hydraulic circuit

In its standard version the line is supplied without pump and without tank. It is however possible to combine dedicated hydronic kits with double or single pump, in standard version or with Inverter.

Condenser

Coils made of copper tubes and aluminum fins.

The W-shape of the coils allows to have high exchange surfaces with small dimensions.

Evaporator

Brazed plates or shell & tube evaporator. Refrigerant electronic expansion valve supplied asstandard.

Control

The electronic microprocessor control allows the constant monitoring of the operating parameters, advanced regulation logics and connectivity.
